Vacuum chamber,Semiconductor equipment precision part

Short Description:

The main function of the vacuum chamber is to provide a closed, highly pure working environment to maintain and ensure a high vacuum state inside.


  • Part name: Vacuum chamber/Semiconductor equpment precision part
  • Material: Aluminium alloy
  • Surface Treament: N/A
  • Main Processing: Turning / Machining Center
  • MOQ: Plan Per Annual Demands and Product Life Time
  • Machining Accuracy: ±0.005mm
  • Key Point: The diameter of the inner hole of the valve block is small, the requirements for the tool and abrasive are high, and the processing is difficult.
  • Product Detail

    Product Tags

    Description

    A vacuum chamber is a device used to maintain and control a vacuum environment. It can create and maintain a specific and controlled vacuum environment, so that various processes or experiments that require low pressure or vacuum conditions can be carried out. For example, metal smelting, vacuum coating, vacuum furnace, etc.

    There are mainly the following types of vacuum chambers: laboratory vacuum chambers, industrial production vacuum chambers and simple vacuum chambers.

    Application

    The main function of the vacuum chamber is to provide a closed, highly pure working environment to maintain and ensure a high vacuum state inside. Such an environment can meet the needs of a variety of industrial and scientific research fields. For example, in the manufacturing process of semiconductor devices, vacuum chambers can ensure the required high-purity environment to ensure the quality and performance of semiconductor devices.

    In addition, the vacuum chamber is composed of a vacuum container, a vacuum system and a vacuum detection device, all three of which cooperate with each other to play their role together. Vacuum containers are usually made of metal materials such as stainless steel, aluminum alloy, etc. These materials not only have good sealing performance and pressure resistance, but can also effectively maintain a vacuum state. Depending on the application requirements, vacuum vessels come in different shapes and sizes, such as cylinders, spheres, cuboids, etc.

    Custom Processing of High-precision Machining Parts

    Machinery Process Materials Option Finish Option
    CNC Milling
    CNC Turning
    CNC Grinding
    Precision Wire Cutting
    Aluminum alloy A6061,A5052,2A17075 , etc. Plating Galvanized, Gold Plating, Nickel Plating, Chrome Plating, Zinc nickel alloy,  Titanium Plating,Ion Plating
    Stainless steel SUS303,SUS304,SUS316,SUS316L,SUS420,SUS430,SUS301,etc. Anodized Hard oxidation ,Clear Anodized,Color Anodized
    Carbon steel 20#、45#,etc. Coating Hydrophilic coating、Hydrophobic coating、Vacuum coating、Diamond Like Carbon(DLC)、PVD (Golden TiN; Black:TiC, Silver:CrN)
    Tungsten steel YG3X,YG6,YG8,YG15,YG20C,YG25C
    Polymer material PVDF、PP、PVC、PTFE、PFA、FEP、ETFE、EFEP、CPT、PCTFE、PEEK Polishing Mechanical polishing, electrolytic polishing, chemical polishing and nano polishing

    Processing Capacity

    Technology Machine List Service
    CNC Milling
    CNC Turning
    CNC Grinding
    Precision Wire Cutting
    Five-axis Machining
    Four Axis Horizontal
    Four Axis Vertical
    Gantry Machining
    High Speed Drilling Machining
    Three Axis
    Core Walking
    Knife Feeder
    CNC Lathe
    Vertical Lath
    Big Water Mill
    Plane Grinding
    Internal And External Grinding
    Precision jogging wire
    EDM-processes
    Wire cutting
    Service Scope:Prototype & Mass Production
    Fast Delivery :5-15Days
    Accuracy :100~3μm
    Finishes: Customized for request
    Reliable Quality Control:IQC,IPQC,OQC

    About GPM

    GPM Intelligent Technology(Guangdong) Co., Ltd. was established in 2004, with a registered capital of 68 million yuan, located in the world manufacturing city – Dongguan. With the plant area of 100,000 square meters, 1000+ employees, R&D personnel accounted for more than 30%. We focus on providing precision parts machinery and assembly in precision instruments, optics, robotics, new energy, biomedical, semiconductor, nuclear power, shipbuilding, marine engineering, aerospace and other fields. GPM has also set up an international multilingual industrial service network with a Japanese technology R&D center and sales office, a German sales office.

    GPM has ISO9001, ISO13485, ISO14001, IATF16949 system certification, the title of National high-tech enterprise. Based on the multi-nationality technology management team with an average of 20 years’ experience and high-end hardware equipment, and quality management system implemented, GPM has been continuously trusted and praised by top-tier customers.

    Frequently Asked Questions

    1.Question: What types of semiconductor equipment parts can you process?
    Answer: We can process various types of semiconductor equipment parts, including fixtures, probes, contacts, sensors, hot plates, vacuum chambers, etc. We have advanced processing equipment and technology to meet various special requirements of customers.

    2.Question: How long is your delivery time?
    Answer: Our delivery time will depend on the complexity, quantity, materials, and customer requirements of the parts. In general, we can complete the production of ordinary parts in 5-15 days at the fastest. For products with complex processing difficulty, we can try our best to shorten the lead time as your request.

    3.Question: Do you have full-scale production capabilities?
    Answer: Yes, we have efficient production lines and advanced automation equipment to meet the demand for high-volume, high-quality parts production. We can also develop flexible production plans according to customer requirements to adapt to market demand and changes.

    4.Question: Can you provide customized solutions?
    Answer: Yes, we have a professional technical team and years of industry experience to provide customized solutions according to specific customer needs and requirements. We can work closely with customers to understand their needs in depth and provide the most suitable solutions.

    5.Question: What are your quality control measures?
    Answer: We adopt strict quality control measures in the production process, including strict inspection and testing at every stage from raw material procurement to product production to ensure product quality and compliance with standards and certification requirements. We also conduct regular internal and external quality audits and evaluations to ensure continuous improvement and optimization.

    6.Question: Do you have R&D team?
    Answer: Yes, we have a R&D team committed to researching and developing the latest technologies and applications to meet customers' needs and market trends. We also collaborate with well-known universities and research institutions to do market research.
